TUOPUONE 8inch Capacitive Touch Display Compatible with Raspberry Pi with 5MP Front Camera 800×480 Resolution DSI Monitor Port
Product details
| Management number | 222251254 | Release Date | 2026/05/04 | List Price | $25.20 | Model Number | 222251254 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Specification Resolution: 800×480 Front Camera: 5MP Display Port: DSI Camera Port: CSI Touch Type: Capacitive Touch Points: 5-Points Touch Port: I2C Touch Panel: Toughened Glass Power Consumption: Low Power Package Content 8inch DSI LCD (with cam) x1 FPC 15PIN 1.0 pitch 50mm (opposite sides) x2 FPC 15PIN 1.0 pitch 120mm (opposite sides) x1 2PIN wire 10cm x1 Screws pack x1
- ✨8-inch capacitive touch screen with a hardware resolution of 800 x 480.Capacitive touch panel, support 5-point touch.
- ✨Toughened glass capacitive panel with up to 6H hardness.OV5647 camera, 500W pixels, 72.9° diagonal field of view, resolution 2592 × 1944.
- ✨Supports Pi 4B/3B+/3A+/3B/2B/B+/A+. Another adapter cable is required for CM3/3+/4a: DSI-Cable-15cm.Directly drive LCD through the DSI interface of RPi, refresh rate up to 60Hz.
- ✨Drive the camera directly through the CSI interface of RPi, the video frame rate supports 1920 × 1080p@30, 1280 × 720p@60, 640 × 480p@60, 640 × 480p@90.
- ✨Working with RPi, supports RPi OS/Ubuntu.Support backlight adjusts by software.
| Brand | TUOPUONE |
|---|---|
| Resolution | FHD 1080p, HD |
| Screen Size | 253 Millimeters |
| Aspect Ratio | 16:10 |
| Display Type | LCD |
| Manufacturer | TUOPUONE |
| Refresh Rate | 60 Hz |
| Mounting Type | Panel Mount |
| Screen Finish | Glossy |
| Viewing Angle | 178 Degrees |
| Native Resolution | 800 x 480 |
| Display Technology | LCD |
| Additional Features | Touchscreen |
| Hardware Connectivity | DisplayPort |
| Connectivity Technology | Ethernet |
| Item Dimensions D x W x H | 0.2"D x 8"W x 5.6"H |
| Specific Uses For Product | Multimedia |
| Display Resolution Maximum | 800x480 Pixels |
| Total Number of HDMI Ports | 1 |
